■ Single 1.5V battery power supply■ Oscillate frequency control can use internal resistor or external resistor■ Built-in low voltage detect function■ SL1124B : 1.35 ±0.05 V ■ Provide fever alarm function■ Automatically turn-off function■ Buzzer alarm indicates ON/OFF button push■ Buzzer alarm indicates no increase in temperature.■ Buzzer alarm indicates fever detected■ Within buzzer alarm interval disable peak temperature latch ■ Bonding option read in the biomedical range of 32.0℃ to 42.0℃(FSEL=NC) or 32.0℃ to 42.9℃(FSEL=VDD)■ Bonding option read in the biomedical range of 89.6℉ to 107.6℉(FSEL=NC) or 89.6℉ to 109.2℉(FSEL=VDD) ■ Bonding option memory function■ Bonding option ℃/℉ changeable by ON/OFF Key or not change mode■ When ℃/℉ changeable mode,push ON/OFF button to select ℃/℉ ■ Bonding option buzzer alarm frequency 4K / 5.3K / 6.4K / 8KHz■ 4 kinds of stable time , 4 sec, 8 sec, 16 sec and 32 sec can be selected by STSEL1K and STSEL2K pads option.
Please refer to the following datasheet
