■ Low noise analog signal path
■ 0.4 mΩ internal conductor resistance
■ Output voltage proportional to AC and DC current
■ Min. sensing current 0~20A at 5V voltage supply
■ High Sensitivity:
BS2702: 1000 mV/A , BS2705: 255 mV/A BS2720: 64 mV/A
■ Wide operating voltage range 3.0~12 V.
■ Low operating current 3mA
■ Nearly zero magnetic hysteresis.
■ Ratiometric output from supply voltage
■ 23K Hz bandwidth
