■ Single 1.5V battery power supply
■ Oscillate frequency control can use internal resistor or external resistor
■ Built-in low voltage detect function
■ SL1124B : 1.35 ±0.05 V
■ Provide fever alarm function
■ Automatically turn-off function
■ Buzzer alarm indicates ON/OFF button push
■ Buzzer alarm indicates no increase in temperature.
■ Buzzer alarm indicates fever detected
■ Within buzzer alarm interval disable peak temperature latch
■ Bonding option read in the biomedical range of 32.0℃ to 42.0℃(FSEL=NC) or 32.0℃ to 42.9℃(FSEL=VDD)
■ Bonding option read in the biomedical range of 89.6℉ to 107.6℉(FSEL=NC) or 89.6℉ to 109.2℉(FSEL=VDD)
■ Bonding option memory function
■ Bonding option ℃/℉ changeable by ON/OFF Key or not change mode
■ When ℃/℉ changeable mode,push ON/OFF button to select ℃/℉
■ Bonding option buzzer alarm frequency 4K / 5.3K / 6.4K / 8KHz
■ 4 kinds of stable time , 4 sec, 8 sec, 16 sec and 32 sec can be selected by STSEL1K and STSEL2K pads option.
